Wacker Neuson RT56SC, RT82SC Trench Roller Service Repair Manual

Description

Table of Content – Wacker Neuson RT56SC, RT82SC Manual

• Safety Information
  • Laws Pertaining to Spark Arresters
  • Operating Safety
  • Operator Safety While Using Internal Combustion Engines
  • Service Safety
  • Label Locations
  • Warning and Informational Labels
• Technical Data
  • Engine
  • Roller
  • Lubrication
  • Sound and Vibration Measurements
  • Dimensions
• Operation
  • Information Regarding Operation
  • Operation and Service Locations
  • Control Panel
  • SmartControl™ Transmitter
  • Infrared System and Control Channels
  • Before Starting
  • Starting
  • Stopping
  • Operation
• Maintenance
  • Transporting Machine
  • Lifting Machine
  • Job Site Storage
  • Storage
  • New Machines
  • Periodic Maintenance Schedules
  • Hydraulic Oil Requirements
  • Hydraulic Oil Level
  • Changing Hydraulic Oil and Filter
  • Articulated Joint, Steering Cylinder, and Hood Hinges
  • Cleaning SmartControl™ Transmitter
  • Drive Gearcase
  • Exciter Lubrication
  • Scrapers
  • Shockmounts
  • Changing Drums
  • Battery
  • Engine Oil System
  • Engine Oil and Filter
  • Air Cleaner
  • Engine Fuel Delivery System Maintenance
  • Fuel Filter
  • Priming the Fuel System
  • Engine Coolant
  • Valve Clearances
  • Adjusting Engine Fan Belt
  • Wiring Schematic
  • Basic Troubleshooting
• Engine Starting Troubleshooting
  • Component Locations
  • Troubleshooting Flowcharts
  • Engine Does Not Crank—Flowchart 1A
  • Checking 20A Fuse
  • Checking Starter Circuit at Trailer Plug
  • Checking Receiving Eyes
  • Replacing Receiving Eye/Light Ring
  • Checking Power to Starter Solenoid
  • Replacing Keyswitch
  • Checking NiCad Battery Charge
  • Engine Cranks but Does Not Start—Flowchart 2A
  • Checking Fuel Line at Fuel Rail Inlet
  • Checking 50A Circuit Breaker
  • Checking Power to Glow Plugs
  • Checking Glow Plugs
  • Checking Relay Wiring
  • Confirming a Malfunctioning Relay
  • Testing ECM
  • Checking Fuel Solenoid
  • Replacing Battery
  • Replacing Trailer Plug
• Hydraulic System
  • Hydraulic Manifold
  • Hydraulic Valves
  • Hydraulic System Pressures
  • Hydraulic Schematics
  • Hydraulic Diagram
  • Hydraulic Diagram Components
  • Exciter Circuit
  • Drive and Brake Circuit
  • High-Speed Drive and Brake Circuit
  • Steering Circuit
• Hydraulic Troubleshooting
  • No Vibration—Flowchart 3A
  • Checking Power to and Operation of Decoder Module
  • Replacing Decoder Module
  • Checking Solenoid Lead
  • Checking Solenoids
  • Replacing Solenoid
  • Checking Pressure at Gauge Port 1 (G-P1)
  • Checking Function of Exciter Motors
  • No Steering Troubleshooting—Flowchart 4A
  • No Travel Troubleshooting—Flowchart 5A
  • Checking Pressure at Gauge Port 2 (G-P2)
  • Checking Function of Brake
  • Checking Function of Drive Motors
  • No High-Speed Travel Troubleshooting—Flowchart 6A
• Disassembly/Reassembly Procedures
  • Tools
  • Ordering Parts
  • Reference Numbers
  • Weight Block
  • Articulated Joint
  • Drum Support Exploded View
  • Drum Support Components
  • Identifying Drum Supports
  • Removing Drums
  • Installing Drums
  • Opening Drum
  • Closing Drum
  • Disassembling Drive Hub
  • Reassembling Drive Hub
  • Disassembling Slave Hub
  • Reassembling Slave Hub
  • Rebuilding Brake
  • Exciter Exploded View
  • Exciter Parts List
  • Disassembling Exciter
  • Reassembling Exciter
  • Removing Drum Support
  • Installing Drum Support
  • Replacing Steering Cylinder
  • Replacing Valve Block
  • Replacing Fuel Tank
  • Replacing Hydraulic Tank
  • Replacing Hydraulic Pumps
  • Replacing Hydraulic Oil Cooler
  • Replacing Radiator and Shroud
  • Replacing Engine
  • Engine Alternator
• Rebuilding Control Box
  • Removing/Rebuilding Joysticks
  • Removing and Installing Circuit Boards
  • Removing and Testing Control Button Circuit Board
