John Deere 1205, 1450, 1650 Tractors Technical Repair Manual (TM1253)

Description

Table of Content (TM1253– Repair Technical Manual)

SECTION 10—GENERAL
Group 00—Specifications and Special Tools
Group 05—Predelivery, Delivery and After-Sale Services
Group 10—Tune-Up
Group 15—Lubrication
SECTION 15—SEPARATION
Group 00—Special Tools
Group 10—Front End
Group 15—Front End and Engine
Group 20—Engine
Group 30—Clutch Housing
Group 35—Transmission
Group 45—Final Drive
SECTION 20—ENGINE REPAIR
Group 00—Special Tools
Group 05—Cylinder Head, Valves, Camshaft and Timing Gears
Group 10—Pistons, Rods, Liners and Cylinder Block
Group 15—Flywheel, Crankshaft, and Main Bearings
Group 20—Lubrication System
Group 25—Cooling System
SECTION 30—FUEL AND AIR SYSTEMS REPAIR
Group 00—Special Tools
Group 05—Air Intake System
Group 10—Diesel Fuel System
Group 15—Speed Control Linkage
SECTION 40—ELECTRICAL REPAIR
Group 00—Special Tools
Group 05—General Information
Group 10—Charging System
Group 15 —Starting Motor
Group 20—Lighting Circuits
Group 25—Gauge Cluster Instrumentation
SECTION 50—POWER TRAIN REPAIR
Group 00—Special Tools
Group 05—1250 Clutch and Linkage Assemblies
Group 06—1450-1650 Clutch and Pedal Linkage
Group 10—Collar Shift Transmission
Group 15—1250 PTO
Group 16—1450-1650 PTO Gear Train
Group 20—Differential
Group 25—Final Drive
Group 30—Mechanical Front-Wheel Drive
SECTION 60—STEERING/BRAKES REPAIR
Group 00—Special Tools
Group 05—Steering Repair
Group 10—Brakes Repair
Group 15—Auxiliary Brake Repair
SECTION 70—HYDRAULIC REPAIR
Group 00—Special Tools
Group 05—Hydraulic Pump and Filters
Group 10—Rockshaft and Implement Hitches
Group 15—Selective Control Valve Repair (Field Option)
SECTION 80—MISCELLANEOUS REPAIR
Group 00—Special Tools
Group 05—Front Axle Assembly
Group 10—Wheels
Group 15 —Operator Station Repair
SECTION 220—ENGINE OPERATION AND TESTS
Group 00—Special Tools
Group 05—System Operation
Group 10—System Tests and Diagnosis
SECTION 230—FUEL/AIR OPERATION AND TESTS
Group 00—Special Tools
Group 05—Air Intake System
Group 10—Diesel Fuel System
Group 15—Speed Control Linkage
SECTION 240—ELECTRICAL OPERATION AND TESTS
Group 00—Special Tools
Group 05—General Information
Group 10—Charging System
Group 15—Starting Circuit
Group 20—Lighting and Accessory Circuits
Group 25—Lighting Circuit Operation
SECTION 250—POWER TRAIN OPERATION AND TESTS
Group 00—Special Tools
Group 05—1250 Clutch
Group 06—1450-1650 Clutch
Group 10—Collar Shift Transmission
Group 15—1250 PTO
Group 16-1450-1650 PTO
Group 20—Differential and Final Drive 1250 Serial No. ( -3000)
Group 21—Differential and Final Drive 1250 Serial No. (3001- ), 1450—1650
Group 30—Mechanical Front Wheel Drive
SECTION 260—STEERING/BRAKES OPERATION AND TEST
Group 00—Special Tools
Group 05—Power Steering
Group 10—Hydraulic Brakes
Group 15—Auxiliary Brakes
SECTION 270—HYDRAULIC OPERATION AND TESTS
Group 00—Special Tools
Group 05—Hydraulic System Operation
Group 10—Hydraulic System Tests
Group 15—Hydraulic Pump
Group 20—Rockshaft and Implement Hitches
Group 25—Selective Control Valve
