Gehl SL4510, SL4610, SL4515 Skid Steer Loader Service Repair Manual

Description

Table of Content Service Repair Manual

Introduction
Specifications
Safety
Decal Locations
Towing A Disabled Loader
Lubrication
Chassis
Drive
Hydrostatic System
Hydraulic System
Electrical System
Engine

This manual has been written and illustrated to help you, the serviceman, in troubleshooting and servicing theSL4010 Series (SL4510, SL4610, SL4515* & SL4615*) Skid Loaders. The material in this manual is the latest in factory service information. It has been compiled by our factory Service.

* SL4515 and SL4615designate newly created model numbers for Industrial Skid Loaders. Although this manual makes specific references to SL4510 and SL4610 units, it should be understood that all information, without Serial Number differentiation, and specific information differentiated as “4510 after SN” and “4610 after SN” is also applicable to respective SL4515 and SL4615 Industrial Skid Loaders.

Follow all procedures carefully, to avoid unnecessary delays and/or damage to the equipment. Where procedures are given in a step-by-step manner, follow them in the order given. Although we have outlined assembly and disassembly procedures for you to follow, there are probably alternate methods that could also work. The Hydraulic System and the Engine are the two most important parts of an SL4010 Series Skid Loader. When any service is performed on the Hydraulics System, always clean the hydraulic component and fittings, before disconnecting any hydraulic lines. Contamination is the greatest cause of failure in Hydraulics Systems. For any Engine repairs, consult your Ford or Perkins Engine Service Manual.

The SL4510 or SL4515* model Loader uses the Ford 98 CID Gasoline Engine. The SL4610 or SL4615* model Loader uses the Perkins 4.108 Diesel Engine.
