Liebherr D934S, D934L, D936L Diesel Engine Service Repair Manual

Description

Table of Content (D934S, D934L, D936L)

This service handbook comprises a summary of the most important maintenance, adjustment and repair tasks, as well as details regarding technical data and tightening specifications for screws for Liebherr diesel engines D934S / L D936 L

• 1. Product description
• 2. Description of basic engine
• 3. Cylinder head
• 4. Lube oil circuit
• 5. Water circuit
• 6. Suction side
• 7. Exhaust side
• 8. Description of the electronic injection system
• 9. Description of the mechanical injection system
• 10. Description of accessories
• 11. Electrical system
• 12. Maintenance
• 13. Fuels
• 14. Mechanical fault list
• 15. Electronic fault list
• 16. Description of level – 1 Parameters and measuring points

Water-cooled 4-cylinder and 6-cylinder inline diesel engine with pump, line, nozzle (PLD) direct injection system, exhaust turbocharging with intercooling and internal, as well as external exhaust gas recirculation ( i AGR, e AGR )
