John Deere 12 Speed Transaxle Repair Component (6D6E, 6×03 Tractors PIN prefix P0 and 6B Tractors PIN prefix CP) Technical Manual (CTM608419)

Description

Table of Content (CTM608419 – Component Technical Manual)

• Section 01 — General Information
  • Group 005 — Safety
  • Group 015 — Transaxle Identification and General Procedures
• Section 02 — Repair and Adjustments Transaxle
  • Group 020 — Component Identification
  • Group 025 — PTO
  • Group 030 — Clutch (Engine) – Dry Clutch
  • Group 035 — Clutch Housing – Dry Clutch
  • Group 040 — Clutch Housing – Wet Clutch
  • Group 045 — Manifold
  • Group 050 — Transaxle
  • Group 055 — Differential
  • Group 060 — Final Drives
  • Group 060A — Hi-Crop Final Drive
  • Group 065 — MFWD Drop Gearbox
  • Group 070 — Brake Repair
• Section 03 — Theory of Operation
  • Group 100 — Transaxle Operation
• Section 04 — Diagnostics
  • Group 150 — Observable Symptoms and System Diagnostics
  • Group 155 — Diagnostic Trouble Code
  • Group 160 — Calibrations, Preliminary Checks, and Operational Checks
  • Group 165 — Schematics
• Section 05 — Tools and Other Materials
  • Group 300 — Essential, Recommended, and Fabricated Tools
  • Group 320 — Other Materials
  • Group 325 — Dealer Fabricated Service Tools
• Section 06 — Specifications
  • Group 410 — Specifications
