CLAAS 6900, 6800, 6700, 6600 (C84) Operators, Technical, Repair Manual

Description

The present CLAAS Repair Manual is to assist in maintaining permanent machine availability. This ensures the high value of your CLAAS machine by
thorough care and service. Experience gathered by both our service engineers and factory staff has been compiled in this Repair Manual.
The sequence of pictures shows the procedure of a repair. The text provides the necessary information about the adjustments to be made, the use of CLAAS special tools etc.
Major repairs are explained in a way that specific and minor repairs can easily be drawn out.
The CLAAS Repair Manual is filled in a folder which allows inserting supplementary pages that cover technical developments and having an updated manual at hand for reference at any time.

To be sure, always compare settings and filling capacities with specifications stated in the current Operator’s Manual of the machine in question.

Texts and figures
Pictures and graphics are neutral. Differences are pointed out by notes beneath the figure. Texts are short and not machine-specific as far as possible. Differences are pointed out by intermediate headings. Different types of texts can easily be distinguished from one another by their formats

Document structure based on sub-assemblies
The chapters are sub-divided into sub-assemblies as far as the content permits. The structure of these subassemblies is the same in all chapters.
